solo_L2_rpw-lfr-surv-bp1 data provides Basic Parameters set 1 (BP1) in survey mode, computed for the three frequency ranges F0, F1, and F2 of the LFR analyser of the Solar Orbiter/RPW instrument. The BP1s consist of seven spectral quantities which aim at characterizing the waves: the total electric and magnetic power spectra, the wave normal vector, a wave ellipticity estimator, a wave planarity estimator, the radial-component of the Poynting vector, and a phase velocity estimator.

L2 Basic Parameters set 1 are fully calibrated in physical units and expressed both in spacecraft reference frame (SRF) and in sensor axis reference frame.

Data have been produced following the method described in Chust et al, 2021 (see references)

Reminder : F0 = 24576 Hz, F1 = 4096 Hz, F2 = 256 Hz and F3 = 16 Hz,

DOI: https://doi.org/10.57780/esa-3xcjd4w

Data product key facts
Type of data Basic Parameters Set 1
Intensity units (V/m²)/Hz, nT²/Hz, nW/m^2/Hz, km/s, or None
Frequency range 10.5 to 9648 Hz in normal mode
120 to 9840 Hz in burst mode
Frequency number 36 in normal mode
48 in burst mode
Frequency step 8Hz (F2), 128Hz (F1) and 768Hz (F2) in normal mode
64Hz (F1) and 384Hz (F0) in burst mode
Frequency scale Linear
Time resolution 4 seconds in normal mode and 1 second in burst mode
Data format CDF (3.9.0)
Granularity 1 file per day

Data organization

Table below gives the name, data type, units and description of the zVariables stored in the CDF file.
In the the “TYPE” column, the expected size (i.e., number of elements along each dimension) of the zVariable for a CDF record is given between bracket (e.g., “[1]”).
Non-record-variant zVariables are indicated by a “(NRV)” additional label in the “TYPE” column.

NAMETYPEUNITDESCRIPTION
Epoch CDF_TIME_TT2000[1] ns Epoch time of the record
Epoch_N_F0 CDF_TIME_TT2000[1] ns Epoch time for F0 frequencies at normal mode
Epoch_N_F1 CDF_TIME_TT2000[1] ns Epoch time for F1 frequencies at normal mode
Epoch_N_F2 CDF_TIME_TT2000[1] ns Epoch time for F2 frequencies at normal mode
Epoch_B_F0 CDF_TIME_TT2000[1] ns Epoch time for F0 frequencies at burst mode
Epoch_B_F1 CDF_TIME_TT2000[1] ns Epoch time for F1 frequencies at burst mode
QUALITY_FLAG CDF_UINT1[1] Flag to indicate the quality of the data
COMMON_BIA_STATUS_FLAG CDF_UINT1[1] LFR common parameters and BIAS status info relevancy flag
QUALITY_BITMASK CDF_UINT1[1] Additional flag to add quality information
L2_QUALITY_BITMASK CDF_UINT1[1] Flag to indicate specific quality issue for L2 data
SURVEY_MODE CDF_UINT1[1] LFR survey mode
FREQ CDF_UINT1[1] Index to indicate the sampling frequency of the snapshot : F0, F1 or F2 in order to use only one skeleton for the 3 normal mode asm products of ICD.
N_F0 CDF_REAL4[11] - NRV Hz Frequencies of BP1 at F0 at normal mode
N_F1 CDF_REAL4[13] - NRV Hz Frequencies of BP1 at F1 at normal mode
N_F2 CDF_REAL4[12] - NRV Hz Frequencies of BP1 at F2 at normal mode
B_F0 CDF_REAL4[22] - NRV Hz Frequencies of BP1 at F0 at burst mode
B_F1 CDF_REAL4[26] - NRV Hz Frequencies of BP1 at F1 at burst mode
BIAS_MODE_MUX_SET CDF_UINT1[1] Copy of multiplexer setting
BIAS_MODE_HV_ENABLED CDF_UINT1[1] Copy of enable/disable HV (+- 100V).
BIAS_MODE_BIAS1_ENABLED CDF_UINT1[1] Copy of enable/disable BIAS 1.
BIAS_MODE_BIAS2_ENABLED CDF_UINT1[1] Copy of enable/disable BIAS 2.
BIAS_MODE_BIAS3_ENABLED CDF_UINT1[1] Copy of enable/disable BIAS 2.
BIAS_ON_OFF CDF_UINT1[1] Copy of BIAS status
BW CDF_UINT1[1] BIAS Works/BIAS Fails configuration
SP0 CDF_UINT1[1] Shaping of electrical data
SP1 CDF_UINT1[1] Shaping of electrical data
R0 CDF_UINT1[1] Rooting of electrical data
R1 CDF_UINT1[1] Rooting of electrical data
R2 CDF_UINT1[1] Rooting of electrical data
BP1_CNT CDF_UINT1[1] Number of BP1 sets read for a given sampling frequency (F0, F1 or F2).
PE_N_F0 CDF_REAL8[11] (V/m²)/Hz Spectral power of E field at F0 in normal mode
PE_N_F1 CDF_REAL8[13] (V/m²)/Hz Spectral power of E field at F1 in normal mode
PE_N_F2 CDF_REAL8[12] (V/m²)/Hz Spectral power of E field at F2 in normal mode
PE_B_F0 CDF_REAL8[22] (V/m²)/Hz Spectral power of E field at F0 in burst mode
PE_B_F1 CDF_REAL8[26] (V/m²)/Hz Spectral power of E field at F1 in burst mode
PB_N_F0 CDF_REAL8[11] nT²/Hz Spectral power of B field at F0 in normal mode
PB_N_F1 CDF_REAL8[13] nT²/Hz Spectral power of B field at F1 in normal mode
PB_N_F2 CDF_REAL8[12] nT²/Hz Spectral power of B field at F2 in normal mode
PB_B_F0 CDF_REAL8[22] nT²/Hz Spectral power of B field at F0 in burst mode
PB_B_F1 CDF_REAL8[26] nT²/Hz Spectral power of B field at F1 in burst mode
NVEC_N_F0 CDF_REAL4[11,3] Wave normal vector from magnetic field at F0 in normal mode
NVEC_N_F1 CDF_REAL4[13,3] Wave normal vector from magnetic field at F1 in normal mode
NVEC_N_F2 CDF_REAL4[12,3] Wave normal vector from magnetic field at F2 in normal mode
NVEC_B_F0 CDF_REAL4[22,3] Wave normal vector from magnetic field at F0 in burst mode
NVEC_B_F1 CDF_REAL4[26,3] Wave normal vector from magnetic field at F1 in burst
NVEC_N_F0_SRF CDF_REAL4[11] Wave normal vector from magnetic field at F0 in normal mode in spacecraft reference frame (SRF).
NVEC_N_F1_SRF CDF_REAL4[13] Wave normal vector from magnetic field at F1 in normal mode in spacecraft reference frame (SRF).
NVEC_N_F2_SRF CDF_REAL4[12] Wave normal vector from magnetic field at F2 in normal mode in spacecraft reference frame (SRF).
NVEC_B_F0_SRF CDF_REAL4[22] Wave normal vector from magnetic field at F0 in burst mode in spacecraft reference frame (SRF).
NVEC_B_F1_SRF CDF_REAL4[26] Wave normal vector from magnetic field at F1 in burst mode in spacecraft reference frame (SRF).
ELLIP_N_F0 CDF_REAL8[11] Wave ellipticity from magnetic field at F0 in normal mode
ELLIP_N_F1 CDF_UINT1[13] Wave ellipticity from magnetic field at F1 in normal mode
ELLIP_N_F2 CDF_UINT1[12] Wave ellipticity from magnetic field at F2 in normal mode
ELLIP_B_F0 CDF_UINT1[22] Wave ellipticity from magnetic field at F0 in burst mode
ELLIP_B_F1 CDF_UINT1[26] Wave ellipticity from magnetic field at F1 in burst mode
DOP_N_F0 CDF_UINT1[11] Degree of polarization from magnetic field at F0 in normal mode
DOP_N_F1 CDF_REAL8[13] Degree of polarization from magnetic field at F1 in normal mode
DOP_N_F2 CDF_REAL8[12] Degree of polarization from magnetic field at F2 in normal mode
DOP_B_F0 CDF_REAL8[22] Degree of polarization from magnetic field at F0 in burst mode
DOP_B_F1 CDF_REAL8[26] Degree of polarization from magnetic field at F1 in burst mode
SX_REA_N_F0 CDF_REAL8[11] nW/m^2/Hz Real parts of the X component of the Poynting vector at F0 in normal mode
SX_REA_N_F1 CDF_REAL8[13] nW/m^2/Hz Real parts of the X component of the Poynting vector at F1 in normal mode
SX_REA_N_F2 CDF_REAL8[12] nW/m^2/Hz Real parts of the X component of the Poynting vector at F2 in normal mode
SX_REA_B_F0 CDF_REAL8[22] nW/m^2/Hz Real parts of the X component of the Poynting vector at F0 in burst mode
SX_REA_B_F1 CDF_REAL8[26] nW/m^2/Hz Real parts of the X component of the Poynting vector at F1 in burst mode
SX_ARG_N_F0 CDF_UINT1[11] Argument bit = 1 if abs(Im(SX)) > abs(Re(SX)) else 0, at F0 in normal mode
SX_ARG_N_F1 CDF_UINT1[13] Argument bit = 1 if abs(Im(SX)) > abs(Re(SX)) else 0, at F1 in normal mode
SX_ARG_N_F2 CDF_UINT1[12] Argument bit = 1 if abs(Im(SX)) > abs(Re(SX)) else 0, at F2 in normal mode
SX_ARG_B_F0 CDF_UINT1[22] Argument bit = 1 if abs(Im(SX)) > abs(Re(SX)) else 0, at F0 in burst mode
SX_ARG_B_F1 CDF_UINT1[26] Argument bit = 1 if abs(Im(SX)) > abs(Re(SX)) else 0, at F0 in burst mode
VPHI_REA_N_F0 CDF_REAL8[11] km/s Phase velocities estimated from the X projection of Maxwell-Faraday equation at F0 in normal mode
VPHI_REA_N_F1 CDF_REAL8[13] km/s Phase velocities estimated from the X projection of Maxwell-Faraday equation at F1 in normal mode
VPHI_REA_N_F2 CDF_REAL8[12] km/s Phase velocities estimated from the X projection of Maxwell-Faraday equation at F2 in normal mode
VPHI_REA_B_F0 CDF_REAL8[22] km/s Phase velocities estimated from the X projection of Maxwell-Faraday equation at F0 in burst mode
VPHI_REA_B_F1 CDF_REAL8[26] km/s Phase velocities estimated from the X projection of Maxwell-Faraday equation at F1 in burst mode
VPHI_ARG_N_F0 CDF_UINT1[11] Argument bit = 1 if abs(Im(SX)) > abs(Re(SX)) else 0, at F0 in normal mode
VPHI_ARG_N_F1 CDF_UINT1[13] Argument bit = 1 if abs(Im(SX)) > abs(Re(SX)) else 0, at F0 in normal mode
VPHI_ARG_N_F2 CDF_UINT1[12] Argument bit = 1 if abs(Im(SX)) > abs(Re(SX)) else 0, at F0 in normal mode
VPHI_ARG_B_F0 CDF_UINT1[22] Argument bit = 1 if abs(Im(SX)) > abs(Re(SX)) else 0, at F0 in burst mode
VPHI_ARG_B_F1 CDF_UINT1[26] Argument bit = 1 if abs(Im(SX)) > abs(Re(SX)) else 0, at F1 in burst mode
SYNCHRO_FLAG CDF_UINT1[1] Flag to indicate if the local time is synchronized with the RPW DPU clock or not. Possible values: synchronized=0, not synchronized=1. This flag is extracted from ACQUISITION_TIME in L0 packets, it is the MSB of the CUC time.
